Specifications
| Test Voltage(DC) | 250V | 500V | 1000V | 2500V | 5000V | ||
|---|---|---|---|---|---|---|---|
| Range | 0.0～104.9MΩ | 0.0～99.9MΩ 80～1049MΩ |
0.0～99.9MΩ 80～999MΩ 0.80～2.09GΩ |
0.0～99.9MΩ 80～999MΩ 0.80～9.99GΩ 8.0～104.9GΩ |
0.0～99.9MΩ 80～999MΩ 0.80～9.99GΩ 8.0～99.9GΩ |
80～1000GΩ | 1001～1199GΩ |
| Accuracy | ±5%+3 | ±5%+3 | ±5%+3 | ±5%+3 | ±5%+3 | ±20% | – |
| Open circuit voltage | DC250V 0%～+20% |
DC500V 0%～+20% |
DC1000V 0%～+20% |
DC2500V 0%～+20% |
DC5000V 0%～+20% |
| Rated current | 3.0mA±0.5mA |
| Short-circuit current | 3mA～4mA |
| Voltage measurement | AC:30～1000V(50/60Hz), DC:30～1000V, Accuracy:±(2%+3dgt) |
| Battery monitor | 4-step indication |
| IP rate | IP54 |
| Battery | LR14(C alkaline battery)1.5V×8 |
| Size/Mass | H188×W225×D97mm/Approx. 1750g |
| Safety standard | IEC61010 CAT.IV 600V |
